•3mm thick, slim front Aluminum bezel(Stainless steel bezel for optional)
•Panel Mount w/mounting clips
•9~36V wide range DC input
•3mm thick, slim front Aluminum bezel(Stainless steel bezel for optional)
•Panel Mount w/mounting clips
•9~36V wide range DC input
Document | file size | Download Link |
---|---|---|
LPM-15R-S | 565.22KB | Download |
Panel Specification | |
---|---|
Size/ Type | 15” (4:3) LCD (LED backlight) |
Resolution | 1024 x 768 @ 60Hz, 75Hz |
Brightness | 250 nits (cd/m2) |
Contract Ratio | 500 : 1 (typ.) |
Max. Colors | 16.2M |
Viewing Angle | -70 ~ 70 (H); -60 ~ 60(V) |
Touch Screen | 5-wire resistive touch screen(optional) |
Active Area | 304.1 (H) x 228.1 (V) |
Pixel Pitch (mm) | 0.297 (H) x 0.297 (V) |
System | |
Mounting Type | Panel mount (w/mounting clips) |
Housing Material | Front black bezel (3mm) with SECC rear metal sheet |
Input / Output | |
USB Ports | 1 x USB for touch |
VGA | 1 x VGA D-Sub 15 pin |
DVI | 1 x DVI-D |
HDMI | N/A |
Video | S-Video, Composite (optional) |
Power Input | 1 x 9~36V DC input (Terminal block) |
Power Specification | |
Power Consumption | 25W typical, normal operation |
Power Input | 9~36V DC input |
Management | VESA DPMS compliant |
Power Cord | N/A |
Environment Specification | |
Operating Temperature | -5 deg. C to 50 deg. C |
Storage Temperature | -40 deg. C to 70 deg. C |
OSD | |
OSD Input | 5-key OSD buttons |
OSD Function | Contrast, Color, Position, Auto-adjustment, Factory Settings |
