LRK-15W-MIL
7U Rackmount Monitor , 15.6" (16:9)LED backlight 1920x1080,
No Keyboard/keypad
Product Code:
LRK-15W-MIL
Availability:
In Stock
- 7U Rackmount Monitor
- 15.6" (16:9) LED backlight 1920x1080,400nits Display
- Military D38999 Connector
- VGA/DVI/HDMI/USB Input
- No Keyboard / keypad
Call for Price： .
- 7U Rackmount Monitor
- 15.6" (16:9) LED backlight 1920x1080,400nits Display
- Military D38999 Connector
- VGA/DVI/HDMI/USB Input
- No Keyboard / keypad
| Document | file size | Download Link |
|---|---|---|
 LRK-15W-MIL |
385.1KB | Download |
| Panel Specification | |
|---|---|
| Size/ Type | 15.6 Inch |
| Resolution | 1920x1080 @60Hz |
| Brightness | 400nits |
| Contract Ratio | 500 : 1 |
| Max. Colors | 262K colors (6 bits) |
| Viewing Angle | -70 ~ 70 (H); -60 ~ 60 (V) |
| Touch Screen | 5-wire resistive touch |
| System | |
| Mounting Type | Rack Mount with handles/flush mount |
| Housing Material | Front Alu.front bezel |
| Keyboard | No keyboard/keypad |
| Input / Output | |
| USB Ports | 1 x USB for touch(D38999 connector) |
| VGA | 1 x VGA(D38999 connector) |
| DVI | 1 x DVI-D(D38999 connector) |
| HDMI | 1 x HDMI (D38999 connector)(optional) |
| Power Specification | |
| Power Adapter | N/A |
| Power Consumption | 25W (typ.) |
| Environment Specification | |
| Operating Temperature | -20 ~ 60 deg.C |
| IP Level | Front IP65 |
| Storage Temperature | -30~70 deg.C |
| Vibration | MIL-STD-810F Method 514.6C-3 |
| Shock | MIL-STD-810F Method 516.6 20G, 11ms |
- 7U Rackmount Monitor
- 15.6" (16:9) LED backlight 1920x1080,400nits Display
- Military D38999 Connector
- VGA/DVI/HDMI/USB Input
- No Keyboard / keypad
