LRK-19R-8U-ML
8U Rackmount Monitor , 19",1280x1024, No Keyboard/keypad
Product Code:
LRK-19R-8U-ML
Availability:
In Stock
- 8U Rackmount Monitor
- 19",1280x1024, 400nits Display
- Military D38999 Connector
- VGA/ DVI /HDMI Input
- 9~36V DC Input
- No Keyboard / keypad
Call for Price： .
- 8U Rackmount Monitor
- 19",1280x1024, 400nits Display
- Military D38999 Connector
- VGA/ DVI /HDMI Input
- 9~36V DC Input
- No Keyboard / keypad
| Document | file size | Download Link |
|---|---|---|
 LRK-19R-8U-ML |
553.29KB | Download |
| Panel Specification | |
|---|---|
| Size/ Type | 19 Inch |
| Resolution | 1280x1024 @60Hz |
| Brightness | 400nits |
| Contract Ratio | 1000 : 1 |
| Max. Colors | 16.7M colors |
| Viewing Angle | -85 ~ 85 (H); -80 ~ 80 (V) |
| Touch Screen | 5-wire resistive touch screen |
| Active Area | 376.32(H) x 301.06 (V) |
| System | |
| Mounting Type | Rack Mount/VESA Mount |
| Housing Material | Heavy Duty Alu.alloy |
| Keyboard | No keyboard/keypad |
| Input / Output | |
| VGA | 1 x VGA(D38999) |
| DVI | 1 x DVI-D(D38999) |
| HDMI | 1 x HDMI (optional) |
| Power Specification | |
| Power Adapter | N/A |
| Power Consumption | 20 W typical,normal operation |
| Power Input | DC Input (D38999) |
| Environment Specification | |
| Operating Temperature | -20 ~ 55 deg.C |
| Operating Humidity | 10~95% (non-condensing) |
| IP Level | Front-IP65 |
| Storage Temperature | -30~70 deg.C |
| Shock | MIL-STD-810G Method 516.6 |
- 8U Rackmount Monitor
- 8U Rackmount Monitor
- 19",1280x1024, 400nits Display
- Military D38999 Connector
- VGA/ DVI /HDMI Input
- 9~36V DC Input
- No Keyboard / keypad
