RDC-19R-ML(-RK)
19” Rugged Rackmount Touch Monitor
Product Code:
RDC-19R-ML(-RK)
Availability:
Pre-Order
Call for Price： .
| Document | file size | Download Link |
|---|---|---|
 RDC-19R-ML(-RK) |
561.86KB | Download |
| Panel Specification | |
|---|---|
| Size/ Type | 19” (5:4) LED backlight |
| Resolution | 1280x1024 |
| Brightness | (1,000nits sunlight readable for optional) |
| Contract Ratio | 1000 : 1(typ.) |
| Max. Colors | 16.7M |
| Viewing Angle | -85 ~ 85 (H); -80 ~ 80 (V) |
| Touch Screen | 5-wire resistive touch or P-cap multi-touch with EMI filter |
| System | |
| Mounting Type | 100 x 100 VESA, Rack mount |
| Input / Output | |
| Serial Ports | 1xRS232(D38999/20FC35SN) |
| DVI | D38999/20FC35SN |
| Power Input | D38999/20FB35SN |
| Environment Specification | |
| Operating Temperature | -20 deg. C to 60 deg. C(-40~60C for optional) |
| Operating Humidity | 10 to 95% (Non Condensing) |
| IP Level | Front-IP66 |
| Storage Temperature | -40 deg. C to 80 deg. C |
| Vibration | MIL-STD-810G Method 514.6C-3 |
| Shock | MIL-STD-810G Method 516.6 |
| EMI/EMC | MIL-STD-461F compliance |
| Dimensions and Weight | |
| Dimensions | 500 (W) x 400(H) x 70 (D) mm |
| Weight | 10KG |
| Order Options | |
| Touch | 5-wire resistive touch screen(for optional) |
| AR Glass | AR Glass (for optional) |
| High brightness | 1,000 nits sunlight readable |
| Optical bonding | Optical bonding w/panel & touch |
| Remote Control | RS232 remote control(for optional) |
