LOF-55W-CP-FST

Stainless Steel front bezel 55” Monitor

Product Code: LOF-55W-CP-FST

Availability: Pre-Order

•Front side wall mount (Mounting the machine from front into the wall, then topping on the front bezel.)

•Stainless steel front bezel

•P-cap multi-touch

•Front side wall mount (Mounting the machine from front into the wall, then topping on the front bezel.)

•Stainless steel front bezel

•P-cap multi-touch

Document	file size	Download Link
LOF-55W-CP-FST	566.16KB	Download

Panel Specification
Size/ Type	55” LCD (LED Backlight)
Resolution	1920 x 1080 @ 60Hz
Brightness	450 nits (cd/m2)
Contract Ratio	5000 : 1 (typ.)
Max. Colors	1073.7M colors
Viewing Angle	-89 ~ 89 (H); -89 ~ 89 (V)
Touch Screen	P-cap multi-touch (USB)
Active Area	1209.6 (H) x 680.4 (V)
Pixel Pitch (mm)	0.63 (H) x 0.63 (V)
System
Housing Material	1. Fringe mount: Open frame to the wall.2. Front side clip: Front bezel topped on the monitor (by tension catch)
I/O chipset	I/O ports at top
Front Bezel	Stainless steel front bezel
Custom cable	5m external cables (power, USB, DP)
Auto On/Off	Auto boot up after powered-in
In-wall thickness	100mm in-wall thickness
Input / Output
USB Ports	1 x USB for touch screen
VGA	1 x VGA D-Sub 15 pin
DVI	N/A
HDMI	N/A
Power Input	1 x AC input
DP	1 x Display Port
Power Specification
Power Adapter	N/A
Power Consumption	300 W typical, normal operation
Management	VESA DPMS compliant
Power Cord	Provided by region
Environment Specification
Operating Temperature	0 deg. C to 45 deg. C
Operating Humidity	10~90%RH (Non-condensing)
IP Level	Front IP54
Storage Temperature	-20 deg. C to 70 deg. C
OSD
OSD Input	5-key OSD buttons
OSD Function	Auto boot-up after powered in

•Front side wall mount (Mounting the machine from front into the wall, then topping on the front bezel.)

•Stainless steel front bezel

•P-cap multi-touch
