FIP-17RBS
17" Stainless FullIP66 (Intel Baytrail Platform)
Product Code:
FIP-17RBS
Availability:
Pre-Order
•Ultra Low Power Intel Celeron Quad Core N2930 1.83GHz
•Either AR glass or Touch Screen in front
•-20~60deg Wide Range Operating Temperature
•Anti-Corrosion Stainless Housing Design
•Full-IP66 Protection
•High Brightness: 1000 nits for optional
•Curve Edge
•Ultra Low Power Intel Celeron Quad Core N2930 1.83GHz
•Either AR glass or Touch Screen in front
•-20~60deg Wide Range Operating Temperature
•Anti-Corrosion Stainless Housing Design
•Full-IP66 Protection
•High Brightness: 1000 nits for optional
•Curve Edge
| Document | file size | Download Link |
|---|---|---|
 FIP-17RBS |
899.09KB | Download |
| Panel Specification | |
|---|---|
| Size/ Type | 17” TFT LCD |
| Resolution | 1280 x 1024 |
| Brightness | 400 nits (cd/m2) |
| Contract Ratio | 1000 : 1 (typ.) |
| Max. Colors | 16.2M (6bits+ FRC) |
| Viewing Angle | -85~85 (H) ; -80~80 (V) |
| Glass | Front AR glass |
| System | |
| System Chipsets | Intel NM10 Chipset |
| System Memory | DDR3 1066MHz SO-DIMM, Default 4GB |
| Storage | 1x 2.5”HDD 500GB or SSD 64GB either one |
| BIOS | AMI 16Mbit Flash |
| WiFi | Built-in 802.11 b/g/n wireless module |
| Ethernet | Broadcom BCM57780 GbE Controller |
| CPU | Intel Celeron M N2930 1.83Ghz |
| Power Input | 12V DC Input (9~36V DC or AC Input for optional) |
| Input / Output | |
| Serial Ports | 2 x RS232 (IP66) |
| USB Ports | 2 x USB (IP66) |
| Ethernet | 1 x RJ45 GbE LAN (IP66) |
| Power | DC 12V (IP66) (w/external power adapter) |
| Power Specification | |
| Power Adapter | 1x AC to DC power adapter(For 12V DC Input model) |
| Power Consumption | 60W (typ.) |
| Environment Specification | |
| Operating Temperature | -20 deg. C to 60 deg. C |
| Operating Humidity | 10% to 95% (Non Condensing) |
| IP Level | Full- IP66 |
| Order Options | |
| High brightness | 1000 cd/m2 (Optional) |
| OS | Windows 7 Professional(Optional) |
| Power Input | 9~36V DC Input (Optional) |
| Platform | Intel® Celeron Bay Trail M N2930 1.83Ghz (Optional) |
| Custom I/O | By request |
| Touch Screen | P-cap touch (Optional) |
•Ultra Low Power Intel Celeron Quad Core N2930 1.83GHz
•Either AR glass or Touch Screen in front
•-20~60deg Wide Range Operating Temperature
•Anti-Corrosion Stainless Housing Design
•Full-IP66 Protection
•High Brightness: 1000 nits for optional
•Curve Edge
