LOF-19W-CP 19” (18.5”) Full-HD LCD Touch Monitor.. Product #: LOF-19W-CP Pre-Order

LOF-19W-CP

19” (18.5”) Full-HD LCD Touch Monitor
Product Code: LOF-19W-CP
Availability: Pre-Order
Document file size Download Link
LOF-19W-CP 575.13KB Download
Panel Specification
Size/ Type 19” wide (16:9, 18.5” in diagonal) LED backlight/AHVA (Kind of IPS series panel)
Resolution 1920 x 1080@ 60Hz
Brightness 350 nits(cd/m2)
Contract Ratio 1000 : 1
Max. Colors 16.7M colors
Viewing Angle -89 ~ 89 (H); -89 ~ 89 (V)
Touch Screen P-cap multi touch screen (USB)
Active Area 409.8 (H) x 230.4 (V)
Pixel Pitch (mm) 0.3 (H)x 0.3 (V)
Input / Output
VGA 1 x VGA D-Sub 15 pin
DVI 1 x DVI-D
HDMI N/A
Video S-Video, Composite (optional)
Power Input 1 x 12V DC input
COM 1 x RS232 for touch (optional)
Power Specification
Power Adapter AC to 12V DC output adapter
Power Consumption 30 W typical, normal operation
Management VESA DPMS compliant
Power Cord Provided by region
Environment Specification
Operating Temperature 0 deg. C to 50 deg. C
Storage Temperature -20 deg. C to 70 deg. C
OSD
OSD Input 5-key OSD buttons
OSD Function Contrast, Color, Position, Auto adjustment, Factory Settings
Order Options
Touch 5-wire, SAW, IR, Capacitive touch for options
AR Glass AR glass protection (optional)
High brightness 1000 nits (optional)
Speaker 2W Speaker x2 (optional)
